Mitutoyo 2900S-10 Dial Indicator, M2.5X0.45 Thread, 8mm Stem Dia., Lug Back, White Dial, 40-0-40 Reading, 57mm Dial Dia…

Amazon.com Price: $80.20 (as of 12/27/2020 20:26 PST- Details)

Description

Range:0-0.08mm  |  Resolution:0.001mm  |  Measurement accuracy:+/-0.003mm  |  Part Number:2900S-10

The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools. Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face. The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use. The grand gear uses stainless steel that is resistant to wear and deformation. Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant.

Make sure this fits by entering your model number.
A carbide contact point is used
Come with limit pins and an outer frame clamp as standard
Shockproof and jeweled bearing
Stem diameter 8mm, M2.5-0.45 thread size
Measuring force: 1.4N or less

Additional information

Product Dimensions
Measurement Accuracy
Part Number
Domestic Shipping
International Shipping
Item model number
Brand
